What is included in a 5kW Hybrid Solar Kit?
11 x certified all black monocrystalline Solar Panels (440W minimum)
(Individual solar panel dimensions are approximately 1,762mm x 1,134mm x 30mm)
1 x 3.68kW Hybrid Inverter (with Wifi Dongle)
1 x 5.18kWh Lithium Ion Battery Module (with heating function)
You can add more 5.18kWh Batteries to increase your storage capacity (at an extra cost)
1 x 50M 4mm Black PV Cable
4 x MC4 Connector (Pairs)
1 x Roof Mount Kit for Tile or Slate Roof (please specify layout when ordering)
2 x 20A, 3 Pole, Lockable, AC Isolators
1 x ECA2 Bi-Directional Single Phase Generation Meter
1 x Solar PV Warning Labels Sheet
1 x Battery Hazard Warning Label Sheet
1 x Installation Manual (inc. warranties and certifications) (via email)
1 x Customised G98 Document Pack (via email)
*Earthing equipment is not supplied (but is required as per the IET Code of Practice for Grid Connected Solar Photovoltaic Systems [1])
*Surge protection is embedded into the Enphase Micro-Inverters, but you must ensure that any additional surge protection is provided (if necessary) to meet the IET Wiring Regulations.
Our kits include ALL the G98 documentation required to commission your installation with your local DNO, as well as step by step instructions on the process.
Hybrid Solar Kit Technical Specifications
Solar Panels
The 5kW (11 Panel) Hybrid Solar Kit is supplied with 11 x 440W MCS certified monocrystalline All Black solar panels. Each solar panel has a 25 year manufacturer’s warranty.
Roof Mount Kit
The 5kW (11 Panel) Hybrid Solar Kit comes with a simple to install roof mounting kit to allow you to fix to a Garage, shed, house, stable or any other outbuilding with a tiled or slate roof. These are warrantied for 10 years.
3.68kW Hybrid Inverter
Max PV power: 5.5kW
Max I (per string): 16A
Max voltage: 600V
Start up voltage: 75V
No. of MPPTs: 2
MPPT Range: 80-550V
Max. efficiency: 97.04%
Charge / discharge efficiency: 98.50%
IP rating: IP65 (indoor or outdoor)
Dimensions: 434mm x 185mm x 418mm
Weight: 22 kg
Warranty: 5 Years
5.18kWh Lithium Ion Battery Module
Battery Type: LifePO4 Prismatic Cell
Includes self-heating element allowing for better charge/discharge at low temperatures
Nominal Capacity: 5.18kWh
Usable Capacity: 4.66kWh
Charge/Discharge Current: 27A
Voltage Range 174V – 219V
Depth of Discharge: 90%
Dimensions (DxWxH): 625mm x 147mm x 380mm
Cycle Life: >4000 (25 C)
IP rating: IP65 (indoor or outdoor)
Number of Parallel Batteries (Max): 4
Weight: 50.5kg
Warranty: 10 Years
Durability
Designed to withstand harsh environmental conditions, these panels often come with a weather-resistant frame and a lifespan of 25 years or more, backed by a manufacturer’s warranty.
Hybrid Inverter Functionality
The hybrid inverter serves as the central unit that converts DC electricity generated by the solar panels into AC electricity for home use, while also managing energy storage and grid interaction.
Battery Integration
Integrating with battery storage systems, allowing for energy storage during peak production times for use during low sunlight periods or power outages.
Smart Features
Hybrid inverters come with advanced monitoring capabilities, enabling real-time performance tracking via mobile applications or web interfaces.
Multi-Mode Operation
Supports multiple operational modes, including grid-tied, off-grid, and backup modes, providing flexibility based on energy needs.
Battery Storage System Type
Typically lithium-ion batteries, known for their high energy density, longevity, and efficiency
Capacity
The battery bank usually has a capacity ranging from 5kWh to 15kWh, allowing for substantial energy storage to power essential appliances during outages or at night.
Cycle Life
Lithium-ion batteries generally offer a cycle life of 3,000 to 5,000 cycles, ensuring long-term reliability and reduced replacement frequency.
Management System
Equipped with a Battery Management System (BMS) that optimizes charging and discharging processes, enhancing battery lifespan and safety.
Mounting System Type
The kit includes a robust mounting system, which can be roof-mounted or ground-mounted, depending on the installation requirements and available space.
Material
Constructed from corrosion-resistant materials such as aluminum or stainless steel, ensuring longevity and stability.
Adjustability
Some mounting systems offer adjustable angles for optimal solar exposure throughout the year, maximizing energy capture.
Wiring and Connectors Quality
Includes high-quality, weather-resistant wiring and connectors that meet industry standards for safety and performance.
Length
Sufficient lengths of wires are provided to connect all components without the need for additional purchases, facilitating a straightforward installation.
Safety Features
The wiring system often includes fuses or circuit breakers to protect against overloads and short circuits.
Charge Controller Type
The kit may include a Maximum Power Point Tracking (MPPT) charge controller, which optimizes the power output from the solar panels.
Functionality
Regulates the voltage and current coming from the solar panels to the batteries, ensuring efficient charging and prolonging battery life.
Display
Many charge controllers come with a digital display that provides real-time data on charging status, battery health, and energy production.
Remote Monitoring
Advanced kits often feature remote monitoring capabilities, allowing users to track system performance via smartphone apps or web portals.
Data Analytics
Provides detailed analytics on energy production, consumption patterns, and system efficiency, helping users make informed decisions about energy use.
Alerts
Some systems include alert functionalities for maintenance needs or system faults, ensuring timely intervention.
Installation Manual and Support Documentation
Comprehensive installation manuals are included, providing step-by-step guidance for installation and setup.
Customer Support
Access to technical support or customer service for troubleshooting and assistance during installation and operation.
Product Warranty
Most components come with warranties ranging from 5 to 25 years, covering defects in materials and workmanship.
Certifications
The kit is typically compliant with international standards and certifications such as IEC, UL, or CE, ensuring safety and performance reliability.
Sustainability
The use of renewable energy sources significantly reduces carbon footprint, contributing to a more sustainable energy future.
Recyclability
Components are often designed with recyclability in mind, minimizing environmental impact at the end of their lifecycle.
